A complex programmable logic device (CPLD) is a logic device with completely programmable AND/OR arrays and macrocells.Macrocells are the main building blocks of a CPLD, which contain complex logic operations and logic for implementing disjunctive normal form expressions. The ispLEVER Classic design software includes all the features necessary to take a project from concept to programmed device. Pricing and Availability. The ispMACH 4032ZE CPLD is available in the 48-TQFP and 64-ball csBGA package. The ispMACH 4064ZE CPLD is available in the 48-TQFP, 64-ball csBGA, 100-TQFP and 144-ball csBGA. The tools used to program a CPLD are very similar to those used to program an In-System Programmable (ISP) microcontroller. The logic circuit is written in a text editor or IDE using a hardware description language. The text file program is then converted to a format that can be loaded into the CPLD. ATF15xx family of industry-standard pin-compatible Complex Programmable Logic Devices. The minimum hardware and software requirements to program an ATF15xx ISP CPLD. CPLD Pin Assignment for the Inverter Tutorial - From the Xilinx Pace Software. Configuring the CPLD. Finish the project by generating the configuration file and then loading the configuration file to the CPLD. The VHDL file, UCF file and output JED file: invert-src-vhdl-ucf-jed.zip (5.8kB).

How To Program A Lattice Cpld Software For Windows 10
How To Program A Lattice Cpld Software Free
How To Program A Lattice Cpld Software For Windows 7

The XPlayer (Jam player) is an inbuilt software tool which comes with SuperPro IS01 programmer software. It allows programming many Altera CPLD and FPGA chips via the JTAG port. XPlayer interprets the information in .jam file to program and test programmable logic devices (PLD) in a JTAG chain. JAM files can be generated using Altera design tools such as ISE and Quartus II. As long as a JAM file is provided, the corresponding device can be programmed using SupePro IS01.

X Player on the Device ' menu bar to bring up the dialogue box below.

Device related information is already included with the .JAM file, so there is no need to select a device for programming. The Device Information box will provide instructions on how to connect the ISP cable to the target PCB.

Below is a list of devices supported by the XPlayer:

Altera Stratix II FPGA device: EP2S60F1020I4N (Quartus 2 tool can create .jam for Stratix II FPGA)
MAX II CPLD series: EPM240/G/Z, EPM570/G/Z, EPM1270/G, EPM2210/G
MAX9000 CPLD series: EPM9320, EPM9320A, EPM9400, EPM9480, EPM9560, EPM9560A
MAX3000A CPLD series: EPM3032A, EPM3064A, EPM3128A, EPM3256A, EPM3512A

Jam file is generated by the Altera design software, and it includes programming algorithm of target devices. Please note that this algorithm cannot be optimized by Xeltek and customer should contact Altera for any issues with .JAM files.
